Elite Slide Out Footrest

1580074 12.10.12This elegant footrest slides fowards and backwards for the ultimate comfort form factor.  It has multiple adjustments for extension. The top of the footrest is made from polyboard with grooves in it for traction.

Bentley’s part# 102211

Features:

                          • Fits on 4″ post
                          • Large 20″ x 7″ platform in an arc sweep
                          • Bottom clamp providing height adjustment and stability, the footrest can swivel to match chair rotation without affecting the height
                          • With 8″ of slide travel, the footrest stores easily under the chair, allowing the user to stand in front of the chair without interference
                          • Note: Can only be used on the Fixed Pedestal
D 3100565 LA WHITE BACKGROUND 2

Elite 24″ Stationary Pedestal w/ Swivel and Slider

Swivel:

D_3100565-LA WHITE BACKGROUND #2D_1450024-P WHITE BACKGROUNDFor the most demanding work boat or pleasure boat applications, Springfield Marine’s Heavy-Duty Slide and Swivel is designed for a fixed pedestal. Offers superior design for rugged service and wobble free control.

Bentley’s part#

Features:

                • 1/4″ thick aluminum swivel plate
                • 10-1/2″ x 14-1/2″ x 1/4″ aluminum formed slide plate
                • Cast, milled, and anodized swivel clamps.
                • Locks onto a 4″ post with a stainless steel pin
                          • Swivel rotates internally on 1/2″ HDPE bearings for a smooth operation in any position
                          • Three lock nut backed bolts provide tension adjustment on the swivel bearing to eliminate any unwanted movement
                          • Swivel control handle has a lockout Position, that allows for a free swivel operation
                          • Large, easy to reach and grip control knobs
                          • Smooth, precise movement in both the slide and swivel operations
                          • 6-7/8″ of total slide travel
                          • Anodized finish

 Pedestal:

This recently redesigned elite aluminum fixed height pedestal is very sturdy and a lovely compliment to your elite seat.

                          • 12″ diameter polished aluminum cast base
                          • 11″ hole pattern and 6 fasteners
                          • 24″ pedestal
                          • 4″ diameter brite dip anodized aluminum post, .213″ wall thickness
                          • Post is sized and pressed into base, then rim welded for stability
1580030 3.27.12

Elite Folding Footrest

1580030 3.27.12This attractive footrest attaches to the bottom of the chair and not the pedestal. It then drops down a comfortable 13-1/2″ below the bottom of the chair, provides a solid footing, and then folds up and out of the way if needed.

Bentley’s part# 102211

Features:

  • Easily mounts to the bottom of the chair for quick installation (hardware not included)
  • Made with a polished high strength aluminum construction
  • 8-1/2″ x 13-1/2″
  • Flips up for an out-of-the-way storage
  • Note: Can be used on both the Fixed Pedestal and the Adjustable Pedestal
3100565 LARA 3.18.11

Elite 24″-32″ Adjustable Pedestal w/ Swivel and Slider

This sturdy locking air seat slide is designed to be used in conjunction with the  Adjustable 4″ post pedestal that adjusts from 22″-32″ and the stowaway footrest.

Bentley part #

Features:

            • Locks snugly onto a 4″ post
              • Heavy duty construction for a stable ride
              • High-strength corrosion-resistant aluminum
              • Stainless steel hardware
              • Internal extra thick bearing provides smooth, 360° rotation
              • Large and easy to reach knobs and handles
              • Travels 6-7″ forward and backward

Bentley’s Featured on KGW News

Video – “Oregon Marine Industry”

HD Swivel Locking 45 Deg 1100050 L

Seat swivel – locking

This Springfield 7″ x 7″ heavy duty swivel locks every 45 degrees. It has a four hole mounting pattern and is powder coated to resist corrosion.

Height: 2″ tall

Hole Pattern:Slotted for variance but 5″ x 5″ center to center

Bentley part # 102184

Tribute Blk Ballistic Nylon 08 12 7

Tribute

Standard Features:

  • Reclining r-bracket
  • Ballistic nylon material w/ toughtek insert
  • ¾” MDO plywood
  • Headrest

Options:

  • Customer’s own material
  • Heated cushion and/or backrest
  • Seaboard upgrade

Dimensions:

  • Overall width – 25”
  • Width inside arm to inside arm – 16”
  • Overall depth – 27”
  • Cushion depth – 17”
  • Height – 24”
  • Shipping box – 28 x 25 x 25
  • Shipping weight – approx. 38 lbs
Cascade Smoke Graphite Website Pic

Cascade

Standard Features:

  • Powder coated welded aluminum folding y-bracket
  • Use up to 3 colors of quality 29.7 oz Naugahyde
  • ¾” MDO plywood

Options:

  • Headrest
  • Reclining r-bracket
  • Ballistic nylon material upgrade
  • Customer’s own material
  • Heated cushion and/or backrest
  • Seaboard upgrade

Dimensions:

  • Overall width – 27”
  • Width inside arm to inside arm – 19”
  • Overall depth – 22”
  • Cushion depth – 18”
  • Height – 24”
  • Shipping box – 28 x 25 x 25
  • Shipping weight – approx. 32 lbs
Folding Bench Seat Surf Mist Mist CS01

Folding Bench Seat

Standard Features:

  • Use up to 3 colors of quality 29.7 oz Naugahyde
  • Folding helm hinge made out of powder coated aluminum
  • ¾ MDO plywood
  • If over 27″ wide, 1″ aluminum square tube inserted in backrest for reinforcement

Options:

  • Armrests
  • Seaboard upgrade
  • Ballistic nylon material upgrade
  • Customer’s own material
  • Heated cushion and/or backrest
  • Variable widths 28″ – 40″
HDM Suspension Swivel Adapter 5 12

Heavy Duty Mechanical Suspension









shown with optional swivel & adapter

Standard Features:



  • Heavy-duty shock absorber
  • 4″  Suspension Motion
  • Self-lubricating bearings
  • Weight/ride adjustment control
  • Boot to cover suspension unit

Options:

  • Adapter to easily mount your existing seat or Bentley’s seat to the suspension unit
  • Heavy-duty swivel with 90 degree positional locks (similar to the mariner swivel in appearance)
  • 6″ track lock slides that allow fore and aft movement (not pictured)

Bentley Part #’s

  • 100545 – Heavy duty mechanical suspension
  • 101605 – Heavy duty mechanical suspension swivel
  • 101573 – Heavy duty mechanical suspension adapter
  • 101286 – Heavy duty mechanical suspension 6″ track lock slides
  • 102200 – Heavy duty mechancial suspension adapter needed instead if 6″ track lock slides purchased (not pictured)

Dimensions of suspension unit:

  • Height – 9″
  • Width – 12″
  • Depth – 16″
  • Shipping box – 20 x 13 x 10
  • Shipping weight – approx. 40 lbs

Dimensions of swivel:

  • Height – 2″
  • Width – 15″ w/ handle
  • Depth – 12 1/2″
  • Shipping box – 20 x 19 x 8
  • Shipping weight – approx. 35 lbs

Dimensions of adapter:

  • Height – 3/4″
  • Width – 12 1/4″
  • Depth – 13 1/2″
  • Shipping box – usually put in suspension unit box w/ unit
  • Shipping weight – approx. 5 lbs
